NuMaker-KE-NUMM7A52H
Evaluation board for KM1M7AF52N
Supplier:
Nuvoton
Certification:
The NuMaker-KE-NUMM7A52H consists of two parts, a KM1M7AF52N platform and an on-board Nu-Link2-Me debugger and programmer.The NuMaker KE-NUMM7A52H allows users to quickly develop and easily program and debug application.
The NuMaker-KE-NUMM7A52H offers KM1M7AF52N full pins extension connectors and Arduino UNO compatible extension connectors. It is an easy-to-develop platform for user to expand the functionality and build the applications. The NuMaker-KE-NUMM7A52H also provides an ammeter connector, allows user to monitor the microcontroller’s power consumption during development.
The Nu-Link2-Me is a debugger and programmer that supports on-line programming and debugging through SWD interface. Nu-Link2-Me provides virtual COM port (VCOM) function to print out messages on PC. Nu-Link2-Me can be separated from NuMaker-KE-NUMM7A52H, allowing user to use as a mass production programming tool.
Ordering No.: KE-NUMM7A52H
Related IC information: KM1M7A/KM1M7AF Digital Power Control Series (Arm® Cortex®-M7)
